Your current location：Home > Products > TWO HEADS HEAVY-DUTY BELT SAND
Beam base and hanging plate are precision castings, low noise and good stability.
The front press roller adopts anti-back device to avoid hurt the operators caused of the rebound of workpiece.
Worm gear lifting motor, stable, powerful and accurate lifting.
| 技術參數(shù) | Technical Specification | SR- RP1300 | SR- R1300 | SR- RP1300X |
|---|---|---|---|---|
| 最大加工寬度 | Max working width | 1300mm | 1300mm | 1300mm |
| 最短加工長度 | Min working length | 530mm | 360mm | 360mm |
| 加工厚度 | Working thinkness | 2-110mm | 2-110mm | 2-110mm |
| 輸送速度（變頻調速） | Feeding speed | 5-30m/min | 5-30m/min | 5-30m/min |
| 砂帶尺寸 | Abrasave belt size | 1330×2200mm | 1330×2200mm | 1330×2200mm |
| 總功率 | Total Moter power | 63.92KW | 79.92KW | 91.42KW |
| 工作壓力 | Working air pressure | 0.6Mpa | 0.6Mpa | 0.6Mpa |
| 壓縮空氣消耗量 | Air consumption | 12m3 /h | 12m3 /h | 12m3 /h |
| 吸塵量 | Volume of dust collection device | 11200m 3 /h | 11200m 3 /h | 11200m 3 /h |
| 外形尺寸 | Overall dimensions | 2036×2382×2150mm | 2036×2470×2150mm | 2036×2382×2150mm |
| 重量 | Net weight | 3850kg | 3950kg | 3950kg |
